Overview
• Combination of Corneal Topographer and built-in Keratometer
• Extremely high resolution (22.000 measuring points) and digital image transmission
• Short measuring time fraction of seconds guarantees high reproducibility
• Non-contact measuring
• Easy to use, because of sophisticated USB interface in Windows™-environment
• Easy to connect to PC via USB-Interface
• Easy to run because of network-capable software
• Easy to mount on a slit lamp
• Refractive compare display to control the progression of wearing Ortho-K-Lenses
• Keratoconus detection and quantification based on several Indices
• Contact lens fitting software with real fluo image simulation, extensive pre-programmed CL database, editing function for your own line of lenses, customized, individual CL lens suggestion
Features
Full Specifications
|
Measurement range: |
0.118″-0.15″, 9-99 D (3-38 mm, 9-99 mm) |
|
Accuracy: |
+/- 0.2 D |
|
Reproducibility: |
+/- 0.2 D |
|
No. of rings: |
22 |
|
Working distance: |
1.6″ (40 mm) |
|
No. of test points: |
22.000 |
|
Dimensions H x D x W: |
8.4″ x 4.1″ x 4.6″ (214 x 103 x 116 mm) |
|
Weight |
1lb 6oz (630 g) |
|
Power supply unit |
Input: 100-240 V Output: 5V/ 1A |
